Overview
Build a real-time chat app using FastAPI (Python) for the backend, PostgreSQL to store messages, Redis for realtime fan-out (pub/sub), and a simple React frontend.
FastAPI Backend
Async Python framework with WebSocket support for real-time messaging.
PostgreSQL + Redis
Reliable message storage with real-time pub/sub for instant delivery.
React Frontend
Simple, responsive interface that connects via WebSocket for live chat.
Architecture
High-level system design with scalable components for real-time messaging.
Client Layer
Web/Mobile clients connect via WebSocket and REST APIs for seamless real-time communication.
Application Layer
FastAPI handles WebSocket connections, message routing, and business logic with async performance.
Data Layer
PostgreSQL stores messages reliably while Redis enables real-time pub/sub message distribution.
Why These Choices?
In plain words - why we picked these technologies for your chat app.
FastAPI
Fast to write, supports async code and WebSockets for real-time connections.
PostgreSQL
Reliable storage for user data and complete message history with ACID compliance.
Redis
Quick message passing between server instances with pub/sub for real-time delivery.
S3/MinIO
Store files like images safely with signed URLs for secure access.
Simple Roadmap
Easy steps to build your chat app from start to finish.
Create Environment
Set up project with poetry/venv and install dependencies
User Auth + WebSocket
Implement signup/login and real-time messaging endpoints
Database + Frontend
Save messages to Postgres and build React chat interface
Commands to Set Up
Copy-and-paste commands to get your chat app running in minutes.
Create Project
poetry init -n poetry add fastapi "uvicorn[standard]" sqlalchemy asyncpg redis[async] passlib[bcrypt] python-jose poetry add -D pytest pytest-asyncio
Run Locally
uvicorn app.main:app --reload --host 0.0.0.0 --port 8000 docker-compose up --build
Minimal Docker Compose
For local development with Postgres + Redis + App.
version: "3.8"
services:
postgres:
image: postgres:15
environment:
POSTGRES_USER: chatuser
POSTGRES_PASSWORD: chatpass
POSTGRES_DB: chatdb
ports:
- "5432:5432"
redis:
image: redis:7
ports:
- "6379:6379"
backend:
build: .
command: uvicorn app.main:app --host 0.0.0.0 --port 8000 --reload
volumes:
- ./:/code
ports:
- "8000:8000"
depends_on:
- postgres
- redis
Tiny FastAPI WebSocket Skeleton
Drop this into app/main.py - very minimal but functional.
from fastapi import FastAPI, WebSocket, WebSocketDisconnect
import json
app = FastAPI()
class ConnectionManager:
def __init__(self):
self.active_connections: dict[int, WebSocket] = {}
async def connect(self, user_id: int, websocket: WebSocket):
await websocket.accept()
self.active_connections[user_id] = websocket
async def disconnect(self, user_id: int):
self.active_connections.pop(user_id, None)
async def send_personal_message(self, user_id: int, message: dict):
ws = self.active_connections.get(user_id)
if ws:
await ws.send_text(json.dumps(message))
manager = ConnectionManager()
@app.websocket('/ws')
async def websocket_endpoint(websocket: WebSocket, token: str = None):
user_id = 1 # validate token -> get user_id
await manager.connect(user_id, websocket)
try:
while True:
data = await websocket.receive_text()
print('received:', data)
except WebSocketDisconnect:
await manager.disconnect(user_id)
Simple SQLAlchemy Models
Clean and concise models for your chat app with SQLAlchemy ORM.
User Model
class User(Base):
__tablename__ = 'users'
id = Column(Integer, primary_key=True)
username = Column(Text, unique=True)
password_hash = Column(Text)
Message Model
class Message(Base):
__tablename__ = 'messages'
id = Column(Integer, primary_key=True)
sender_id = Column(Integer, ForeignKey('users.id'))
recipient_id = Column(Integer, ForeignKey('users.id'))
content = Column(Text)
created_at = Column(DateTime, default=datetime.datetime.utcnow)
delivered = Column(Boolean, default=False)
How Messages Flow
Step-by-step journey of a message from sender to recipient
Message Flow Steps
Client A Sends Message
User sends message via WebSocket to server instance
Server Saves to Database
Message stored in PostgreSQL for durability
Redis Pub/Sub Event
Server publishes event to Redis channel for recipient
Broadcast to Instances
All servers receive event and forward if recipient online
Client Receives Message
Recipient client receives message and sends ACK
Flow Benefits
Durability
Messages saved to PostgreSQL before broadcasting ensures no data loss
Real-time
Redis pub/sub provides sub-millisecond message delivery
Scalability
Multiple server instances can handle thousands of concurrent users
